Specifications of the NC Computers
Feature |
|
|
|
||||||
| Processor | Z80 | Z80 | Z80 | ||||||
| Screen | LCD 480 x 64 pixels (80 x 8 chars) |
LCD 480 x 64 pixels (80 x 8 chars) |
LCD Backlit 480 x 128 pixels (80 x 16 chars) |
||||||
| RAM | 64kb | 128kb | 128kb | ||||||
| Backup | PCMCIA slot (Max. 1Mb) |
PCMCIA slot (Max. 1Mb) Option to connect Ranger Disk floppy drive |
PCMCIA slot (Max. 1Mb) 3.5" 720K MS-DOS compatible Disk Drive |
||||||
| Ports | Parallel Centronics Serial RS232 |
Parallel Centronics Serial RS232 |
Parallel Centronics Serial RS232 |
||||||
| 'Sticky shift' for disabled users | Yes | Yes | Yes | ||||||
| Power supply | 4 x AA cells 6V Mains adaptor |
4 x AA cells 6V Mains adaptor |
5 x C cells 7.5V Mains adaptor |
||||||
| Word Processor -- 48,000 word spell-checker Macros Mail merge Protext, Wordstar 3.3 and ASCII file formats |
Yes | Yes, but spell-checker for French or Italian and no Wordstar format | Yes | ||||||
| Calculator -- Delete feature 12 digits Large display Memory |
Yes | Yes | Yes -- also previous calculation history display | ||||||
| Diary -- Uses word processor to edit entries dates from 1920 to 2099 Calendar display Print by day/week/year |
Yes | Yes | Yes | ||||||
| Address book -- Find feature Import address into document Use as mail-merge data file |
Yes | Yes | Yes -- also extra fields | ||||||
| Time -- Six alarms with messages Six editable time zones Computer switches on to activate alarm |
Yes | Yes | Yes | ||||||
| BBC BASIC programming language | Yes | Yes | Yes | ||||||
| Serial Terminal | Yes | Yes | Yes | ||||||
| Games -- Blockade Super Blockade Trikade |
No | Yes | Yes | ||||||
| Spreadsheet -- Cracker compatible Draws and prints graphs/charts |
No | Yes | Yes |
 |
|
|
